Autotherm Premium Insulated Door ONLINE INSTANT Quote

Our Autotherm Premium range of garage doors come in a choice of colours and 2 textured woodgrain finishes. The door has been engineered to produce a premium product which not only protects your home but it’s aesthetically pleasing appearance also enhances it.

Our doors are made to measure, which means you get the perfect fit for your garage. Due to the design of the Autotherm door, it can be adapted to accommodate most types of garages, even those with arches. All doors are CE marked for Quality and Safety.

  • Premium quality Italian remote control system complete with 2 compact handsets
  • The ultimate combination of insulation, ease of use, and security
  • High performance
  • Self locking
  • Safety edges on the bottom of the doors
  • Internal manual override facility

See full description and specification below or download brochure here

  • Description
  • Specification

Autotherm construction

All Autotherm doors are constructed from interlocking 77mm twin walled aluminium slats and filled with CFC-free insulating foam, which combines strength whilst helping increase energy efficiency with a typical U value of 5.2 w/m2 K. The doors can easily span an opening up to 4800mm wide and come with a heavy duty weather seal to the bottom section.

Security

Auto locking is actively engaged via the anti-lift geometry locking straps when the door is closed.

Safety

All Premium Autotherm doors have an anti-drop safety brake and come with a wireless bottom rail safety edge which when detecting an object whilst descending, will auto reverse the direction of the door. The system also does a complete safety test each time it is operated. It also has a safety exclusion in the 'down' direction which is used in the scenario of an uneven floor, where normally magnets would be required. The door remote control system as has an anti-entrapment in the 'up' position, removing the need to fit a full box to the door.

Remote control operation

Each Premium Autotherm door comes with a high quality remote control system including 2 handsets. Rolling code technology ensures that security is paramount with a unique code generated each time the handset is activated. The remote control unit comes complete with surface mounted 'up', 'down' and 'stop' buttons, has a built in courtesy light, and come complete with a 3-pin plug.

Motors

At the time of manufacture, all motors are designed to lift at least double the weight of the door that they are being fitted to. In the event of a power failure, a manual winding handle ensures that the door can be opened from inside the garage. An external manual winding system is also available as an optional extra.

Headroom

Roller doors are perfect for garages with limited headroom as the tight roll of the door requires on y 300mm of headroom for doors up to 3000mm in height. This allows additional roof space in your garage and maximises the drive through height for taller vehicles. Please note that approximately 70mm of the bottom of the door will be visible below the opening, when the door is in the open position.

Guide rails

The guide rails are available in a white, black, bown or anthracite polyester powder coated finish and incorporate double neoprene and brush pile seals, which help prevent against draughts, whilst increasing the insulation value of the door. (Please note that the colour of the guide rails may vary slightly from the door curtain).

Side plates

Once fully retracted, the curtain is housed between two side plates, which locate into the guide rails via a cast aluminium leg. This helps distribute the weight of the door onto the guides, whilst simplifying the installation. The curtain is then assisted on its descent by two nylon rollers mounted onto the base of the side plates, which helps reduce wear and makes the door run smoother.

Side room

The Autotherm door can be installed either within the opening (reveal fix) if the side room is limited or behind the opening (face fix), allowing any old timber frames to be removed and maximising the drive through width.

Housing cover box (optional extra)

A front fascia section and back cover can be supplied as an optional extra, in either a white,black, bown or anthracite finish. This helps increase the weather protection and insulation, whilst making the door even more aesthetically pleasing.

Guarantees

All of our door types are fully compliant and have been independently tested by a UKAS accredited testing laboratory. They are CE marked and come with the relevant declarations. All doors have a 12 month guarantee.

Specification

77mm x 18 mm thick foam filled aluminium slats with CFC free foam

Typical U value of 5.2w/m2 k

90mm white, black, bown or anthracite  aluminium guides with double neoprene strip and brush pile

300mm roll size white, black, bown or anthracite coloured 300mm end plates

Anti-drop safety brake

Bottom rail safety edge

High quality Italian remote control with rolling code technology, complete with 2 handsets

Separate up-stop-down buttons fitted on the remote control box

Internal manual override facility

Auto Locking is automatically engaged via the anti-lift geometry locking straps

Heavy duty rubber weather seal to bottom of the door

Rollers to feed door curtain into guides for reduced wear and smoother operation

Built in courtesy light

Pre-wired 3 pin plug

Fully compliant - independently tested by a UKAS accredited testing laboratory and come with the relevant Declarations

CE marked

mm
mm
You can select only one from 90 degree fascia panel (half box) and Back box cover including fascia (full box).










Colours are for illustration purposes only.
Delivery Options: Delivery Charges will be added at checkout:

Delivery Charges will be added at checkout

England and Wales, excluding postcodes EX, TQ, PL, TR, LD, LL, SY and SA £60.00

Postcodes Ex, TQ, PL, TR, LD, LL, SY and SA £90.00

Scotland postcodes - Phone for a price

Collect from factory £0.00

£0.00
per item, including vat
